Product ID: M-6310
Short Description:

Build-in 2x15W digital amplifier
1 AUX input, 1 MIC input, 1 AUX output, 1 EMC output
Support offline local source playing

M-6310 IP network terminal player is a network full digital signal processor based on TCP/IP protocol. With dual network interface design, it can be connect to anywhere at network reaches. Under intelligent control of the system center, this terminal serves to output the long distance audio data flow.

Built in USB port and SD slot for local program playing. With 1 AUX input for connect with other audio source equipment; 1 AUX audio output for connection with other amplifiers for power extension; 1 MIC input for local Paging.

◆ Dual Network interface design, able to work across network segments
◆ Able to connect to anywhere at network reaches
◆ Built in USB port and SD slot for local program playing
◆ Support up to 48kHz sampling frequency, and 16bit digital audio code stream decoding
◆ Built in 2x15w with low power consumption setting
◆ Able to play the background music, emergency broadcast, warning signal from system center
◆ 1 AUX input, 1 AUX output, 2 MIC input, 1 EMC output

 Model   M-6310
 AUX in     Input sensitivity  350V
 Frequency response   26Hz-18kHz
 Distortion  ≤0.5%
 SNL  ≥75 dB
 AUX out     Rated output  1000mV
 Frequency response  25Hz-20kHz
 Distortion  ≤0.3%
 SNL  ≥75 dB
 Distortion  Distortion  3.5mV
 Frequency response  30Hz-18kHz
 Distortion  ≤0.5%
 SNL  ≥65 dB


USB/SD/NET/MP3 Display


 Frequency response  25Hz-20kHz
 Distortion  ≤0.5%
 SNL  ≥70dB
 Capacity of SD card supported  32GB
 Capacity of  U disk supported  32GB
 Power supply    AC180-250V/50Hz-60Hz
 Display screen    Digital Screen
 Net weight (Kg)  1.2
 Dimension(L×W×H mm)  132×140×50
