L-401THS/L-501THS/-L-601THS series in-ceiling fireproof speakers offering two tweeter dome solutions, one is for silk soft dome and the other is Titanium dome.

This series ceiling speakers are built with the right mix of robust audio parts and components to have a balance for affordability and performance, is part of LYINTL’s premium ceiling speakers that are elegantly designed for easy and seamless for multi-room background audio system and high-performance home theater music system.

Frameless magnetic grille design for easy and secure attachment.

This series indoor ceiling speakers are coming with 4", 5" or 6.5" Graphite cone material woofer speaker driver and 0.75" or 1" silk or Titanium dome tweeter, with 70V/100V transformer.

Power taps:
L-401THS: 2.5/5/10/20W/8Ω     (4" graphite + 0.75" silk)
L-501THS: 3.75/7.5/15/30W/8Ω (5" graphite + 1" Titanium)
L-601THS: 5/10/20/40W/8Ω      (6.5" graphite + 1" Titanium)

With fireproof iron rear cover suitable for emergency evacuation system usage.



FS-3430 indoor on wall surface mount loudspeakers are coming with very elegant and sleek housing design, build-in 2pcs 4" low frequency woofer speaker driver and 1pc 1" high frequency silk soft dome tweeter.



Power handing (RMS): 30W (60W Max)
4" x 2 (100mm) Polypropylene cone woofer, rubber surround
1" x 1 (25mm) Silk soft dome tweeter

This speaker can be widely used in schools, gyms, squares, parks, train stations, airports, villas, supermarkets, shopping malls and other places where need high quality sound level.



This series subwoofers are most popular powered home theater subwoofer with component upgrades for thrilling home theater bass sound.

◆ Triple woofer design includes One Active Graphite Paper Cone Woofer and Two Passive Glass Fiber Cone Woofers to deepen bass, minimize distortion and maximize the performance of your surround sound speakers.

◆ Custom coded Native EQ for unparalleled bass extension helps subwoofer acheive supremely low bass notes down to 16Hz extensions

◆ Works with free and premium iWoofer App to customize bass output from your smartphone or tablet (premium iOS only)



World Class Digital Amplifier Technology

The DSP Series powered active subwoofer incorporates the latest digital amplifier technology to maximize performance while generating very little heat. In standby mode, the unit consumes less than 0.5 watts, making it one of the greenest solutions available.

Tuned System Performance

Rear mounted volume control, low pass crossover, phase control and App controlled DSP ensure optimal system integration and built-in native EQ ensures the deepest bass frequencies.

Cabinet

An attractive furniture quality solid cabinet with ‘leather’ finish, provides the foundation for high sound quality and clarity.

This landscape garden speaker is coming with a 100V transformer, which is realized in a high-voltage, low-current mode, which makes longer distance transmission and parallel connection of multiple loudspeakers possible.

High quality engineering plastic enclosure, weatherproof and heavy damage proof finish.

Easy and secure installation in outdoor area.

It is a good ideal choice for industrial and commercial applications in the outdoor area such as parks and zoos where background music and paging is needed.



This compact mixing amplifier is designed as convenient solution for small PA installations with USB player, Bluetooth and FM tuner receiver in a compact housing,  and this amplifier features 2 unbalanced microphone input and 2 AUX inputs, moreover the MIC1 has "VOICE PRIORITY" over the other inputs except for the alarm input, moreover a group of line level output is available for adding additional amplifier.

Equipped with step-up transformer to be best suitable for any 70V and 100V line public address system, in the same time 4~16 Ohm output load is also provided.

Level controllers include individual volume controller for inputs,master volume controller for all, BASS and TREBLE tone controllers.

Complete protection is provided for over temperature, over voltage, over load and short circuit speaker line conditions.



◆ Built-in music streaming media including USB/SD card player, FM tuner and Bluetooth receiver

◆ 70V/100V and 4~16Ω output loads

◆ 2 Microphone (MIC1 & MIC2) inputs, MIC2 supports 48V Phantom power with switch ON/OFF

◆ EMC input has priority over the other inputs

◆ SMT circuit boards with highly stable performance

◆ High-definition display for the working status of playing programme

◆ Individual volume controller for inputs,and master volume controller for all

◆ BASS and TREBLE tone individual control

◆ Power supply AC100-240V and DC24V

◆ Protection provided for output short circuit, overload, high temperature, peak current limiters


Designed to blend within any outdoor setting, the SUB-3010 is a powerful and stealthy outdoor rated subwoofer that enhances outdoor sound systems by adding crucial bass notes for a more enriching surround sound experience.

SUB-3010 cranks out 150W of power and includes a 10” graphite cone woofer and a high impact molded plastic enclosure with a unique antique bronze finish.

Truly weather-resistant, the SUB-3010 is IP66 rated which means it is 100% sealed and protected from dirt and dust as well as powerful water jets such as sprinklers.

Its unique curved shape and down-firing port makes it the perfect addition to decks and porches, but you can place it anywhere you run speaker wire. For optimal performance, however, we recommend placing this subwoofer on a paved or hard surface.

The SUB-3010 also includes a built-in eye bolt that allows you to anchor it to the location to prevent theft or to keep it firmly in place.

This subwoofer speaker suits for any of landscape satellite speakers, and you’ll have an outdoor audio system that rivals your indoor system.

Features:

● Heavy-duty weather-resistant outdoor subwoofer for backyards, porches and patios

● IP66 rated and protected from dirt, dust and sprinklers

● Rated at an 150W to deliver powerful low frequency sound effects

● Down-firing port with 10” graphite cone woofer

● Antique bronze finish blends easily in the backyard lighting landscapes

● Withstand rain, snow and high temperatures

HS-6 series outdoor on wall mount / ceiling pendant speakers are part of LYINTL’s wall mount audio products line with very elegant and sleek housing design.

This seireis have 1 x 1" high frequency tweeter driver, and for low frequency woofer driver, 4", 5", 6.5" and 8" respectively.

Made from carefully selected premium grade material for durability,  HS-5 series wall mount speakers come within the superior housing design with cutting edge audio component & parts that will deliver great audio sound results.

Exclusive OBE Technology

Optimal BASS Enhancement (OBE) Technology delivers an outstanding deep and clear bass audio experience even without any extra subwoofer support.

Ceiling pendant and wall mount kits are optional, suitable for both indoor and outdoor usage.

Specification

● 3 mounting method: on wall mounted, ceiling pendant, and in-ground stand (8" only)

● Build-in 70V/100V transformer and 8Ω power taps

● 1×4”, 1×5”, 1×6½” or 1x8" graphite woofer speaker driver and 1" silk tweeter

● Rated output power: 20W, 30W, 40W or 50W

● IP66 all weatherproof, suitable for indoor and outdoor use

● White and black color for option
